Total Power 14,4 @ 2 Ohms

4 x 100 WRMS

Total Power 14,4 @ 4 Ohms

4 x 70 WRMS

Total Power 14,4 Bridged @ 2-4 Ohms

2 x 200 WRMS

Efficiency @ 4 Ohms

84%

Efficiency @ 2 Ohms

77%

Input Voltage

9 – 15V

Input Impedance

22K Ohms

THD+Noise

0,10%

Input Sensitivity

140mV – 680V

SNR

85dB

Frequency Response

5 to 22KHz (-3dBs)

HPF (High Pass Filter)

20 to 90Hz @ 12dB/octave Linkwitz-Riley

LPF (Low Pass Filter)

90 to 20kHz @ 12dB/octave Linkwitz-Riley

Recommended Fuse

30 A

Current at Rest

1 A

Average Current Draw (Sinusoidal)

30 A

Average Current Draw (Music)

20 A

Power Wire Gauge (min. Recommended)

6mm / 9 AWG

Speaker Wire Gauge (min. Recommended)

2 x 1,5mm / 2 x 15 AWG

Weight (Lb)

1,8

Height (in)

1,6

Width (in)

4,8

Depth (in)

8,0
